Nexans PV H1Z2Z2-K SUN PLUS Cable (1.5kV DC)
Nexans PV H1Z2Z2-K SUN PLUS Cable (1.5kV DC)
Nexans PV H1Z2Z2-K SUN PLUS cables (1.5kV DC) are designed to comply with the international standards of the solar plants.
They are dedicated to the photovoltaic system direct current (D.C.) side with a nominal D.C. voltage of 1.5 kV and a maximum D.C. voltage of 1.8 kV.
These cables are suitable for permanent outdoor long-term use, under variable and harsh climate conditions.
They are designed and tested to operate at a normal maximum conductor temperature of 90°C and for 20,000 hours up to 120°C. Therefore, the expected period use is 30 to 40 years under normal usage conditions (lifetime acc. to Arrhenius-Diagram).
ENERGYFLEX 1X6 EN50618 One Stripe RG D500
Nexans ref. 10206375
- Packaging: Drum (m)
- Sheath colour: Black with red stripe
ENERGYFLEX EN50618 1x4 ONE Stripe RED D500
Nexans ref. 10206312
- Packaging: Drum (m)
- Sheath colour: Black with red stripe
ENERGYFLEX® 1x10mm² D500
Nexans ref. 10191000
- Packaging: Drum (500m)
- Sheath colour: Black (blue or red stripe on request)
ENERGYFLEX® 1x16mm² D500
Nexans ref. 10185635
- Packaging: Drum (500m)
- Sheath colour: Black (blue or red stripe on request)
ENERGYFLEX® 1x4mm² D500
Nexans ref. 10191003
- Packaging: Drum (500m)
- Sheath colour: Black (blue or red stripe on request)
ENERGYFLEX® 1x6mm² D500
Nexans ref. 10191094
- Packaging: Drum (500m)
- Sheath colour: Black (blue or red stripe on request)
Nexans PV H1Z2Z2-K Energyflex 1x10mm² NR
Nexans ref. 10191044
- Packaging: Drum (m)
- Sheath colour: Black (blue or red stripe on request)
Nexans PV H1Z2Z2-K Energyflex 1x4mm² NR
Nexans ref. 10189494
- Packaging: Drum (m)
- Sheath colour: Black (blue or red stripe on request)
Nexans PV H1Z2Z2-K Energyflex 1x6mm² NR
Nexans ref. 10189495
- Packaging: Drum (m)
- Sheath colour: Black (blue or red stripe on request)
Description
Description
Standards
-
ProductEN 50618; IEC 62930
-
TestEN 60332-1-2; EN 61034-2
Application
Nexans PV H1Z2Z2-K SUN PLUS Cable (1.5kV DC)
PV
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Dimensional characteristics
Dimensional characteristics
Electrical characteristics
Electrical characteristics
Mechanical characteristics
Mechanical characteristics
Usage characteristics
Usage characteristics
