Nexans iOption for Power over Ethernet is an optional extension to enable PoE, PoE+ or PoE++ on the RJ45 interfaces of the iGigaSwitch and XGigaSwitch series.
Meer
Beschrijving
Beschrijving
| Ordering Information | iOption PoE+ 2/4-30W | iOption PoE+ 6/8-30W | iOption PoE+ 10/12-30W | iOption PoE++ 2/4-90W | iOption PoE++ 6/8-90W |
| Article number | 88301602 | 88301604 | 88301606 | 88301664 | 88301666 |
| Number of PoE ports | 2 or 4 | 6 or 8 | 10 or 12 | 2 or 4 | 6 or 8 |
| Max. output power per port | 30W | 30W | 30W | 90W | 90W |
| Total output power | 120W | 240W | 360W | 360W | 540W |
| Capable with | |||||
| iGigaSwitch 1002 | x | x | |||
| iGigaSwitch 1004 | x | x | x | x | |
| iGigaSwitch 1008 | x | ||||
| iGigaSwitch 1604 | x | x | x | ||
| iGigaSwitch 1606 | x | x | |||
| iGigaSwitch 1608 | x | x | |||
| iGigaSwitch 1612 | x | ||||
| XGigaSwitch DICE | x | x |
